Remote Dimming Module (RDM)
More lighting control. Less complexity.
More lighting control. Less complexity.
Control more zones
Expand lighting control across the building without adding unnecessary complexity.
Dim automatically
Adjust lighting based on schedules and operating needs to reduce energy use.
Manage remotely
Change lighting schedules and settings without making a trip to the location.
Works as one system
Connect directly into your Entouch system for centralized building control.
Specifications
The details that decide procurement.
Physical | |
|---|---|
Dimensions | 5.5” × 2.625” × 1.5” |
Weight | 4.5 oz |
Mounting | Wall mounted |
POWER | |
Input Power | 24VAC · 50/60Hz · 2W |
Power Source | DLC or 120VAC-to-24VAC transformer |
LIGHTING CONTROL | |
Control Input | 0–10V PWM dimming |
Dimming Outputs | Four isolated 0–10V PWM outputs |
Photocell | Resistive photo sensor input · photo sensor pass-through |
Output Type | Open-collector sink |
Pullup | 10mA for compatible drivers |
Supported Lighting | LED · incandescent · magnetic low-voltage · electronic low-voltage · 2-wire dimmable fluorescent |
CONNECTIVITY | |
Connection | Hardwired to DLC |
Origin | Made in USA |
Built to run the building for you.
Every device. One platform.
All Entouch hardware reports natively into the platform— so every watt, degree and runtime hour lands on the same screen.
